Quick Details

  • Use For: Passenger
  • Driving Type: Electric
  • Power: > 800W
  • Voltage: 48V
  • Body Type: Open
  • Certification: CE
  • Brand Name: ZZMERCK
  • Place of Origin: Henan, China (Mainland)
  • Model Number: M-TB01
  • Size: 3100*1100*1850mm
  • Motor: 48V 1000W brushless DC permanent magnet differential motor
  • Battery: 12V 60Ah Lead-acid battery*4
  • Charging time: 6-8 hours
  • Max. speed: 25km/h
  • Max. Driving distance: 105km
  • Loading capacity: 300kg
  • Climbing capacity: 20%
  • Max. braking distance: 4m
  • Gear system: Shimano 7 gears
  • Tire size: 2.75-18

Packaging & Delivery

Packaging Details Fully assembled in iron case, Packing size 310*123*200cm with our electric cycle rickshaw with pedal assist
Delivery Time 20days after get the deposit

6 Speed Pedal Assist Bicycle Battery Auto Electric Rickshaw, Electric Tricycle Adults 2 Passenger Pedicab Rickshaw

Product Description

Our electric tricycle rickshaw are a new kind of urban transportation and the perfect way to get around city. No air pollution. No noise. No hassle. Bike taxis are three-wheeled modern style rickshaws with open windows that carry up to two passengers,which is a green power substitute of cars and buses



Originally electric tricycle rickshaw is a German design, they are pedal-powered ,but our pedicab rickshaw come with 1000W brushless differential motor, 48V 60Ah Lead acid, 1:1 pedal assist and Shimano 3*7 Gears, The full endurance distance is up to105km.



Electric tricycle rickshaw design is aimed at meeting people’s demand for a vehicle----beauty, convenience, and environmental protection. Taxi Service,  Wedding Service, Mobile Advertisement, We can do it all !!!  Mobile Advertisement:

The electric tricycle rickshaw are lightweight fiberglass with steel sub-frame and are available in a variety of colors, which make the pedicab cute and lovely. It is convenient for the passenger to see the scenery along the street. Its fiber glass frame protects the visitors and drivers from storm and rain.



Unlike normal rickshaw, the driver seat is slant, it's similar with recumbent trike very comfortable and relaxed while driving, and the back two seats can contain up to 2 passenger with 33"(L)*13’’(W).





This electric tricycle rickshaw  is smaller than cars and buses. So it is able to move flexibly among crowded streets. Braking is provided by a revolutionary hydraulic disc brake, its max braking distance is only 4 meter. Thus it is easy to stop the bike safely.





It's with 3 LCD digital meters, clearly indicating lights, speed, and power.





Our electric tricycle rickshaw  is equipped with 1000W brushless differential motor, 48V 60Ah Lead acid, 1:1 pedal assist and Shimano 7 Gears, The full endurance distance is up to105km.this taxi bike car is environmental friendly with electric power instead of petrol motor. Thus it does not pollute the environment.





Product Details



During the last 10  years of developing our products we have a designed a range of probably the highest quality Vehicals in the World. Our vehicles have been under heavy trials before going into bulk production. During our trials we have improved our vehicles not only in quality but also safety and functinality. That's why we are so confindent that our cycles belong to the best group in the world.



Basic Specification



1. Motor: 48V 1000W brushless DC permanent magnet differential motor

2. Battery: 12V 60Ah Lead-acid battery*4
3. Controller: 48V 1000W brushless controller
4. Steering fork: shoulders type damper front fork
5. Damper(rear): drum spring damper(rear)
6. Brake: disc(hydraulic manual control)
7. Max. braking distance: 4m
8. Loading capacity: 300kg
9. Climbing capacity: 20%
10. Parking capacity: 20%
11. Max. speed: 25km/h
12. Max. Driving distance: 105km
13. Vehicle size: 3100*1100*1850mm
14. Tire size: 2.75-18
15. Wheel base: 2500mm; wheel interval: 1040mm
16. Front light: LED energy saving double headlights
17. Meter: 3 LCD digital meters, indicating lights, speed, power
18. Gear system: Shimano 7 gears
19. Frame: glass fiber reinforced plastics
20. Net weight: 200kg
21. Charging time: 6~8 hours

22. Beep when turning and reversing



We also can install the safety belt for the Passenger seat, MP3 player, Extra Brake light, USB charging outlet and GPS, but it depends on customer's request.



Note: For European customers, inorder to meet your countries’ requirements of electric vehicle, now we also have New Upgraded 250W model Electric Rickshaw which accord with European standard.
(our electric drive according the European law (having a torque sensor, working only when pedaling, max constant power 250W, speed only up to 25Km/h).

Certifications



The CE Certificates of electric cycle rickshaw with pedal assist.





Packaging & Shipping



Our packing of the electric cycle rickshaw with pedal assist.



The package of the rickshaw is very big. So it can only be shipped by sea.

The container loading: 20"FCL: 4 pieces.  40"FCL: 8 pieces

The rickshaw is fully assembled in iron case:



FAQ



Q1: What colors are available?
A: The cabin is made of 100% recyclable PE (polyethylene),colored plastic. The standard color is white.



Q2: How fast does it go?
A: The top speed is electronically limited to 25 kph for safety reasons.



Q3: How many miles can it travel on a single charge?
A: It depends on weight, assistance, terrain, weather conditions etc. The estimated range is 50 miles (80 km).



Q4: How much weight can the bike carry?
A: The bike is rated to carry a total of 300 kg, including the rider.



Q5: Can it go up hills with 2 passengers on them?
A: It is designed for urban transport and traveling on a flat route. It can only go up slight hills.



Q6: Why don't you mount the side doors?
A: The open design of the velotaxi helps preserve the sense of joy and freedom that is inherent in riding the bike. What's more, the open body provide a good view for passengers while travel among tourist attractions.



Q7: Does it have a storage place under the passenger seat?
A: It doesn't have. But the rear seat of the cabin provides room for two passengers with hand luggage.



Q8: Does it come fully assembled or do I have to put it together?
A: For one sample, it comes 80% assembled. For 2 or more, we will ship them by full container load. They will come fully assembled.
